背景说明

应用系统的日志收集与分析工作对运维来说至关重要。常见的系统解决方案中开源技术栈ELK（Elastic Stack: Elasticsearch, Logstash, Kibana）是当前比较流行的选择。下面我们会讨论另一种构建于云原生设计的类似于ELK的解决方案EKK（Amazon Elasticsearch Service, Amazon Kinesis, and Kibana）。

EKK的优势在于组件是AWS托管服务，不必自己安装、运维，并且与AWS的其它服务轻松集成，可以很轻松的部署一套可靠、可扩展、安全、容错以及解耦和基于事件的解决方案。

传统的Elasticsearch中，日志数据的不断膨胀，对数据的生命周期管理越来越重要（应对此需求的新功能ILM(index lifecycle management)在Elasticsearch 7.0中闪亮登场）。本文不介绍ILM，介绍另一种解决方案：使用Lambda配合实现数据的轮换。

使用Lambda在ES轮换数据数据（Rotate）

1. 为Lambda设置IAM Role

2. 在Lambda中创建个Layer(层)

把项目需要的依赖包放到层里，方便Lambda的使用。

层参考： https://docs.aws.amazon.com/zh_cn/lambda/latest/dg/configuration-layers.html

参考命令：

$mkdir python$pip3 install elasticsearch-curator -t ./python/$zip -q -r layer.zip ./python

3. 创建Lambda： ES-Rotate

设置Lambda运行的Layers

保存

设置运行代码，点击

在下面Function code区域更新代码，host地址换成我们创建的ES Cluster地址

import json

import boto3

from requests_aws4auth import AWS4Auth

from elasticsearch import Elasticsearch, RequestsHttpConnection

import curator



host = 'search-ekk-log-vpfpqvgbxnom3ctwvz5evv2du4.cn-north-1.es.amazonaws.com.cn' # For example, search-my-domain.region.es.amazonaws.com

region = 'cn-north-1' # For example, us-west-1

service = 'es'

credentials = boto3.Session().get_credentials()

awsauth = AWS4Auth(credentials.access_key, credentials.secret_key, region, service, session_token=credentials.token)





def lambda_handler(event, context):

es = Elasticsearch(

hosts = [{'host': host, 'port': 443}],

http_auth = awsauth,

use_ssl = True,

verify_certs = True,

connection_class = RequestsHttpConnection

)



index_list = curator.IndexList(es)

index_list.filter_by_age(source='name', direction='older', timestring='%Y-%m-%d', unit='days', unit_count=1)

print("Found %s indices to delete" % len(index_list.indices))



# If our filtered list contains any indices, delete them.

if index_list.indices:

curator.DeleteIndices(index_list).do_action()





# TODO implement

return {

'statusCode': 200,

'body': json.dumps('Hello from Lambda!')

}

修改Lambda 运行时内存和超时时间

4. 测试

定义测试用例输入参数，

因此Lambda测试用例，不需输入参数，可使用默认设置，

运行测试用例

在ES中查看

参考 https://docs.aws.amazon.com/zh_cn/elasticsearch-service/latest/developerguide/curator.html

5. 在CloudWatch设置定时轮换

Load to ES from S3

1. 创建Lambad s3-to-es-bulk-by-hour

2. 设置Layer

3. 设置Code

Bucket 设置为Kinesis Firehose 中设置的bucket

Host 设置为ES 的endpoint

import boto3  import re  import requests  from requests_aws4auth import AWS4Auth  import json  from elasticsearch.helpers import bulk  import time  from elasticsearch import Elasticsearch, RequestsHttpConnection      region = 'cn-north-1' # e.g. us-west-1  service = 'es'  credentials = boto3.Session().get_credentials()  awsauth = AWS4Auth(credentials.access_key, credentials.secret_key, region, service, session_token=credentials.token)    bucket = 'zhnc-ekk-full-log'    host = 'search-ekk-log-vpfpqvgbxnom3ctwvz5evv2du4.cn-north-1.es.amazonaws.com.cn'  type = 'log'  headers = { "Content-Type": "application/json" }    s3 = boto3.client('s3', region_name=region)    def get_all_s3_keys(bucket, prefix):  keys = []  kwargs = {'Bucket': bucket, 'Prefix':prefix}  while True:  resp = s3.list_objects_v2(**kwargs)  for obj in resp['Contents']:  keys.append(obj['Key'])  try:  kwargs['ContinuationToken'] = resp['NextContinuationToken']  except KeyError:  break  return keys      # Lambda execution starts here  def lambda_handler(event, context):    print(event)  for record in event['Records']:  msg = json.loads(json.dumps(eval(record['Sns']['Message'])))  year=msg['year']  month=msg['month']  day=msg['day']  hour=msg['hour']  index = 'apachelog-{}-{}-{}-{}'.format(year,month,day,hour)    print(index)    keys = get_all_s3_keys(bucket,"apachelog/{}/{}/{}/{}".format(year,month,day,hour))    print(len(keys));    es = Elasticsearch(  hosts = [{'host': host, 'port': 443}],  http_auth = awsauth,  use_ssl = True,  verify_certs = True,  connection_class = RequestsHttpConnection  )      for key in keys:    ACTIONS = []  obj = s3.get_object(Bucket=bucket, Key=key)  body = obj['Body'].read()  lines = body.splitlines()    for line in lines:    document = json.loads(line)  action = {  "_index": index,  "_type": type,  "_source": document  }  ACTIONS.append(action)  success, _ = bulk(es, ACTIONS, index=index, raise_on_error=True)  print('Performed %d actions' % success)

4. 设置运行内存，超时时间

5. 测试

这个Lambda将被SNS触发，创建一个模拟SNS的事件，

消息Message 设置为将要测试的事件，Lambda会读取对应的S3文件到ES中，

消息内容为，

{

"Records": [

{

"EventSource": "aws:sns",

"EventVersion": "1.0",

"EventSubscriptionArn": "arn:aws-cn:sns:cn-north-1: 725362542198:s3-to-es-by-day:caf9a3b1-679c-4604-9b65-f15dca3b5b18",

"Sns": {

"Type": "Notification",

"MessageId": "71c6da65-49bf-5301-8270-8ff199faaa1b",

"TopicArn": "arn:aws-cn:sns:cn-north-1: 725362542198:s3-to-es-by-day",

"Subject": "None",

"Message": "{'year':'2019','month':'06','day':'30','hour':'02'}",

"Timestamp": "2019-07-02T03: 22: 45.020Z",

"SignatureVersion": "1",

"Signature": "ihaGN/JL8u/v57xEY1RTFekpUpgVukM9Ebj9IIM9Rr9KGkUMe6dO7hze7estD0yM9K0QRQAreQ5XiB0Tfj/jOCvyjL9IrRcTplQcWPzMHmVqd4C3942gduFkHyul2+lYa0DJZM46J/Yy7mihe9EfXUySf2Eyok4NsUC6WtnbyJPN17FG1t4fnEWpRwU2Yg+MLM4bJWr3sK5/6xRnUVerLlMm5tCsynybW6FQCYsVgl7SJLW6nBmbCe3v6jRMuKCNW8xptVyEAnII4h5uPVElts0IWhnE+EQG3FNFmOZmj8OLZutRadSrNFexRMZebmKwRZRD5dTaCoD5E6v6TTYGbQ==",

"SigningCertUrl": "https: //sns.cn-north-1.amazonaws.com.cn/SimpleNotificationService-3250158c6506d40f628c21ed8dad1787.pem",

"UnsubscribeUrl": "https://sns.cn-north-1.amazonaws.com.cn/?Action=Unsubscribe&SubscriptionArn=arn:aws-cn:sns:cn-north-1:725362542198:s3-to-es-by-day:caf9a3b1-679c-4604-9b65-f15dca3b5b18",

"MessageAttributes": {}

}

}

]

}

此事例将读取以下位置的日志文件

点击测试

ES Index已经导入

作者简介

陈朕，AWS解决方案架构师，负责基于AWS云计算方案架构的咨询和设计，在国内推广AWS云平台技术和各种解决方案。十余年分布式应用、大数据的分布式处理经验。

本文转载自AWS技术博客

原文链接：

https://amazonaws-china.com/cn/blogs/china/ekk-amazon-elasticsearch-service-amazon-kinesis-and-kibana/

创作场景

搭建云上日志收集分析系统（三）
