背景

推荐排序dnn模型中经常会用一些特别稀疏的id特征，此时需要对这些id特征做embedding操作，一般在tensorflow中都会使用一个shape=[id_index_size, embedding_size]的Variable 矩阵做embedding参数，然后根据id特征的index去Variable矩阵中查表得到相应的embedding表示。这里需要注意的是：id_index_size的大小一般都不会等于对应id table的元素个数，因为有很多id元素不在原始的id table表中，比如新上架的一些商品等。此时需要将id_index_size设置的大一些，以留一些位置给那些不在id table表的元素使用。那么从原始的id特征值映射成[0, id_index_size)间的index是怎么做的呢？

如果id量非常小的话，可在特征提取后把id排序一遍生成从0开始的连续id值，但在工业界的场景下id特征的量级往往是百万到上亿级别，很难做排序。幸好tensorFlow内部有一个函数可以将原始的id特征值映射到从0开始的index，这个函数就是lookup.index_table_from_tensor。

例子

首先举一个index_table_from_tensor的使用例子：

import tensorflow as tf

sess = tf.Session()
vocabulary_list = tf.constant(["emerson", "lake", "palmer"])
table = tf.contrib.lookup.index_table_from_tensor(
        vocabulary_list=vocabulary_list, num_oov_buckets=10, default_value=-1)
features = tf.constant(["emerson", "lake", "and", "palmer", "dad", "mom", "hello"])
table.init.run(session=sess)
ids = table.lookup(features)
print(sess.run(ids))

返回值：[ 0  1 10  2  9  3  9]

index_table_from_tensor函数的作用是：如果在vocabulary_list里面的id特征值，则映射为从0到len(table)-1之间的index，如果不在vocabulary_list里面，则通过hash函数映射到len(table)至len(table) + num_oov_buckets - 1之间的区间中。

我们开始分析源代码，首先看下index_table_from_tensor的源码：

def index_table_from_tensor(vocabulary_list,
                            num_oov_buckets=0,
                            default_value=-1,
                            hasher_spec=FastHashSpec,
                            dtype=dtypes.string,
                            name=None):
  """Returns a lookup table that converts a string tensor into int64 IDs.
  This operation constructs a lookup table to convert tensor of strings into
  int64 IDs. The mapping can be initialized from a string `vocabulary_list` 1-D
  tensor where each element is a key and corresponding index within the tensor
  is the value.

  Args:
    vocabulary_list: A 1-D `Tensor` that specifies the mapping of keys to
      indices. The type of this object must be castable to `dtype`.
    num_oov_buckets: The number of out-of-vocabulary buckets.
    default_value: The value to use for out-of-vocabulary feature values.
      Defaults to -1.
    hasher_spec: A `HasherSpec` to specify the hash function to use for
      assignment of out-of-vocabulary buckets.
    dtype: The type of values passed to `lookup`. Only string and integers are
      supported.
    name: A name for this op (optional).
  Returns:
    The lookup table to map an input `Tensor` to index `int64` `Tensor`.
  Raises:
    ValueError: If `vocabulary_list` is invalid.
    ValueError: If `num_oov_buckets` is negative.
  """

  “”“
  类型检查代码
  ”“”

  with ops.name_scope(name, "string_to_index") as feat_to_id_scope:

    # 获取由传入的vocabulary_list构造的hash表，keys是vocabulary_list里面的元素，values是
    # 【0， len(num_elements）-1】
    keys = ops.convert_to_tensor(vocabulary_list)
    num_elements = array_ops.size(keys)
    values = math_ops.to_int64(math_ops.range(num_elements))

    shared_name = ""
    with ops.name_scope(None, "hash_table") as hash_table_scope:
      table_keys = math_ops.to_int64(keys) if keys.dtype.is_integer else keys
      init = KeyValueTensorInitializer(
          table_keys,
          values,
          table_keys.dtype.base_dtype,
          dtypes.int64,
          name="table_init")
      table = HashTable(
          init, default_value, shared_name=shared_name, name=hash_table_scope)
    if num_oov_buckets:
      table = IdTableWithHashBuckets(
          table,
          num_oov_buckets=num_oov_buckets,
          hasher_spec=hasher_spec,
          name=feat_to_id_scope,
          key_dtype=dtype)
    return table

从上面的代码片段可以看出，index_table_from_tensor函数体中有三个比较重要的步骤：

根据keys和values创建KeyValueTensorInitializer。
根据KeyValueTensorInitializer创建具体的HashTable类，对于不在vocabulary_list表里面的元素，统一返回默认值。
如果num_oov_buckets>0，则会创建带有Buckets的IdTableWithHashBuckets类，用一个hash函数返回那些不在vocabulary_list表里面的id元素的index值。
首先我们来分析第一步的操作，先通过传入的vocabulary_list去构造keys和values，然后传入到KeyValueTensorInitializer类中返回table初始化的op，注意此时只是返回一个用于table初始化的OP，还没有做具体的初始化工作（初始化要放到具体的HashTable中去完成）。下面看下KeyValueTensorInitializer的代码：

class KeyValueTensorInitializer(TableInitializerBase):
  """Table initializers given `keys` and `values` tensors."""

  def __init__(self, keys, values, key_dtype=None, value_dtype=None, name=None):
    with ops.name_scope(name, "key_value_init", [keys, values]) as scope:
      self._keys = ops.convert_to_tensor(keys, dtype=key_dtype, name="keys")
      self._values = ops.convert_to_tensor(
          values, dtype=value_dtype, name="values")
      self._name = scope

    super(KeyValueTensorInitializer, self).__init__(self._keys.dtype,
                                                    self._values.dtype)

  def initialize(self, table):
    """Initializes the given `table` with `keys` and `values` tensors.
    Args:
      table: The table to initialize.
    Returns:
      The operation that initializes the table.
    Raises:
      TypeError: when the keys and values data types do not match the table
      key and value data types.
    """
    _check_table_dtypes(table, self._keys.dtype, self._values.dtype)
    with ops.name_scope(
        self._name, values=(table.table_ref, self._keys,
                            self._values)) as scope:
        init_op = gen_lookup_ops.lookup_table_import_v2(
            table.table_ref, self._keys, self._values, name=scope)
    ops.add_to_collection(ops.GraphKeys.TABLE_INITIALIZERS, init_op)
    return init_op
可看出table的初始化操作是通过lookup_table_import_v2这个op来完成，下面就分析下这个op的相关c代码：

REGISTER_OP("LookupTableImportV2")
    .Input("table_handle: resource")
    .Input("keys: Tin")
    .Input("values: Tout")
    .Attr("Tin: type")
    .Attr("Tout: type")
    .SetShapeFn( {
      ShapeHandle handle;
      TF_RETURN_IF_ERROR(c->WithRank(c->input(0), 0, &handle));

      ShapeHandle keys;
      TF_RETURN_IF_ERROR(c->WithRank(c->input(1), 1, &keys));
      TF_RETURN_IF_ERROR(c->Merge(keys, c->input(2), &keys));
      return Status::OK();
    });

// Clear the table and insert data.
class LookupTableImportOp : public OpKernel {
 public:
  explicit LookupTableImportOp(OpKernelConstruction* ctx) : OpKernel(ctx) {}

  void Compute(OpKernelContext* ctx) override {
    lookup::LookupInterface* table;
    OP_REQUIRES_OK(ctx, GetLookupTable("table_handle", ctx, &table));

    “”“
    ....
    ”“”

    const Tensor& keys = ctx->input(1);
    const Tensor& values = ctx->input(2);
    OP_REQUIRES_OK(ctx, table->CheckKeyAndValueTensorsForImport(keys, values));

    int memory_used_before = 0;
    if (ctx->track_allocations()) {
      memory_used_before = table->MemoryUsed();
    }
    OP_REQUIRES_OK(ctx, table->ImportValues(ctx, keys, values));
    if (ctx->track_allocations()) {
      ctx->record_persistent_memory_allocation(table->MemoryUsed() -
                                               memory_used_before);
    }
  }
};

这里通过table_handle句柄来传入具体的Table类，上面举的例子中使用的是HashTable类，HashTable类继承于InitializableLookupTable类，InitializableLookupTable可理解为那些需要初始化操作的table集合，而InitializableLookupTable又继承于LookupInterface类。通过table->ImportValues()方法来将vocabulary_list中构造的keys和values导入到hash表中，完成hash表的初始化工作。

通过LookupTableImportV2返回init_op之后，将该初始化hash表的op传给HashTable类，HashTable类和其父类的代码如下：

class HashTable(InitializableLookupTableBase):

  def __init__(self, initializer, default_value, shared_name=None, name=None):
    """Creates a non-initialized `HashTable` object.
    Creates a table, the type of its keys and values are specified by the
    initializer.
    Before using the table you will have to initialize it. After initialization
    the table will be immutable.
    Args:
      initializer: The table initializer to use. See `HashTable` kernel for
        supported key and value types.
      default_value: The value to use if a key is missing in the table.
      shared_name: If non-empty, this table will be shared under
        the given name across multiple sessions.
      name: A name for the operation (optional).
    Returns:
      A `HashTable` object.
    """
    with ops.name_scope(name, "hash_table", (initializer,
                                             default_value)) as scope:
      table_ref = gen_lookup_ops.hash_table_v2(
          shared_name=shared_name,
          key_dtype=initializer.key_dtype,
          value_dtype=initializer.value_dtype,
          name=scope)

      super(HashTable, self).__init__(table_ref, default_value, initializer)
      self._value_shape = self._default_value.get_shape()


class InitializableLookupTableBase(LookupInterface):
  """Initializable lookup table interface.
  An initializable lookup tables persist across different steps.
  """

  def __init__(self, table_ref, default_value, initializer):
    """Construct a table object from a table reference.
    If requires a table initializer object (subclass of `TableInitializerBase`).
    It provides the table key and value types, as well as the op to initialize
    the table. The caller is responsible to execute the initialization op.
    Args:
      table_ref: The table reference, i.e. the output of the lookup table ops.
      default_value: The value to use if a key is missing in the table.
      initializer: The table initializer to use.
    """

    name = table_ref.op.name.split("/")[-1]
    super(InitializableLookupTableBase,
          self).__init__(initializer.key_dtype, initializer.value_dtype,
                         name)
    self._table_ref = table_ref
    self._default_value = ops.convert_to_tensor(
        default_value, dtype=self._value_dtype)
    self._default_value.get_shape().merge_with(tensor_shape.scalar())
    self._init = initializer.initialize(self)

  @property
  def table_ref(self):
    """Get the underlying table reference."""
    return self._table_ref

  @property
  def default_value(self):
    """The default value of the table."""
    return self._default_value

  @property
  def init(self):
    """The table initialization op."""
    return self._init

  def lookup(self, keys, name=None):
    """Looks up `keys` in a table, outputs the corresponding values.
    The `default_value` is used for keys not present in the table.
    """
    key_tensor = keys
    with ops.name_scope(name, "%s_Lookup" % self._name,
                        (self._table_ref, key_tensor,
                         self._default_value)) as scope:
      values = gen_lookup_ops.lookup_table_find_v2(
          self._table_ref, key_tensor, self._default_value, name=scope)

    values.set_shape(key_tensor.get_shape())
    if isinstance(keys, sparse_tensor.SparseTensor):
      return sparse_tensor.SparseTensor(keys.indices, values, keys.dense_shape)
    else:
      return values

InitializableLookupTableBase类继承于HashTable，InitializableLookupTableBase类中有init操作和look_up，所以表的初始化和look_up操作其实都是在父类中完成，其中表的初始化操作上面已经讨论过，我们就重点看下look_up操作的相关OP：


lookup_table_find_v2

// Table lookup op. Perform the lookup operation on the given table.
class LookupTableFindOp : public OpKernel {
 public:
  explicit LookupTableFindOp(OpKernelConstruction* ctx) : OpKernel(ctx) {}

  void Compute(OpKernelContext* ctx) override {
    lookup::LookupInterface* table;
    OP_REQUIRES_OK(ctx, GetLookupTable("table_handle", ctx, &table));

    “”“
    ......
    ”“”

    const Tensor& key = ctx->input(1);
    const Tensor& default_value = ctx->input(2);
    OP_REQUIRES_OK(ctx, table->CheckFindArguments(key, default_value));

    TensorShape output_shape = key.shape();
    output_shape.RemoveLastDims(table->key_shape().dims());
    output_shape.AppendShape(table->value_shape());
    Tensor* out;
    OP_REQUIRES_OK(ctx, ctx->allocate_output("values", output_shape, &out));

    OP_REQUIRES_OK(ctx, table->Find(ctx, key, out, default_value));
  }
};

REGISTER_KERNEL_BUILDER(Name("LookupTableFind").Device(DEVICE_CPU),
                        LookupTableFindOp);
REGISTER_KERNEL_BUILDER(Name("LookupTableFindV2").Device(DEVICE_CPU),
                        LookupTableFindOp);

# table->Find调用的是HashTable类的DoFind方法
Status DoFind(const Tensor& key, Tensor* value,
                const Tensor& default_value) override {
    const V default_val = default_value.flat<V>()(0);
    const auto key_values = key.flat<K>();
    auto value_values = value->flat<V>();

    for (int64 i = 0; i < key_values.size(); ++i) {
      value_values(i) = gtl::FindWithDefault(
          *table_, SubtleMustCopyIfIntegral(key_values(i)), default_val);
    }
    return Status::OK();
  }

最后我们分析下IdTableWithHashBuckets类，该类可用一个hash函数返回那些不在vocabulary_list表里id元素的index值，先举个例子：

import tensorflow as tf
num_oov_buckets = 3
input_tensor = tf.constant(["emerson", "lake", "palmer", "king", "crimnson"])
table = tf.IdTableWithHashBuckets(
      tf.HashTable(tf.TextFileIdTableInitializer(filename), default_value),
      num_oov_buckets)
out = table.lookup(input_tensor).
table.init.run()
print(out.eval())

#filename依次为"emerson", "lake", "palmer"

#结果为[0, 1, 2, 4, 7]
下面看下IdTableWithHashBuckets的源码：

class IdTableWithHashBuckets(LookupInterface):
  """String to Id table wrapper that assigns out-of-vocabulary keys to buckets.
  For example, if an instance of `IdTableWithHashBuckets` is initialized with a
  string-to-id table that maps:
  * `emerson -> 0`
  * `lake -> 1`
  * `palmer -> 2`
  The `IdTableWithHashBuckets` object will performs the following mapping:
  * `emerson -> 0`
  * `lake -> 1`
  * `palmer -> 2`
  * `<other term> -> bucket_id`, where bucket_id will be between `3` and
  `3 + num_oov_buckets - 1`, calculated by:
  `hash(<term>) % num_oov_buckets + vocab_size`
  If input_tensor is `["emerson", "lake", "palmer", "king", "crimson"]`,
  the lookup result is `[0, 1, 2, 4, 7]`.
  If `table` is None, only out-of-vocabulary buckets are used.
  """

  def __init__(self,
               table,
               num_oov_buckets,
               hasher_spec=FastHashSpec,
               name=None,
               key_dtype=None):
    """Construct a `IdTableWithHashBuckets` object.
    Args:
      table: Table that maps `tf.string` or `tf.int64` keys to `tf.int64` ids.
      num_oov_buckets: Number of buckets to use for out-of-vocabulary keys.
      hasher_spec: A `HasherSpec` to specify the hash function to use for
        assignation of out-of-vocabulary buckets  (optional).
      name: A name for the operation (optional).
      key_dtype: Data type of keys passed to `lookup`. Defaults to
        `table.key_dtype` if `table` is specified, otherwise `tf.string`.
        Must be string or integer, and must be castable to `table.key_dtype`.
    Raises:
      ValueError: when `table` in None and `num_oov_buckets` is not positive.
      TypeError: when `hasher_spec` is invalid.
    """
    # If a name ends with a '/' it is a "name scope", remove all trailing '/'
    # characters to use as table name.

    “”“
    类型检查
    “”“

    self._num_oov_buckets = num_oov_buckets
    super(IdTableWithHashBuckets, self).__init__(key_dtype, dtypes.int64,
                                                 name.split("/")[-1])

  @property
  def init(self):
    """The table initialization op."""
    if self._table:
      return self._table.init
    with ops.name_scope(None, "init"):
      return control_flow_ops.no_op()

  @property
  def table_ref(self):
    if self._table is not None:
      return self._table.table_ref
    return None

  def _get_string_to_hash_bucket_fn(self, hasher_spec):
    """Returns the string_to_hash_bucket op to use based on `hasher_spec`."""
    if not isinstance(hasher_spec, HasherSpec):
      raise TypeError("hasher_spec must be of type HasherSpec %s" % hasher_spec)
    if hasher_spec.hasher == "fasthash":
      return string_ops.string_to_hash_bucket_fast
    if hasher_spec.hasher == "legacy":
      return string_ops.string_to_hash_bucket
    if hasher_spec.hasher == "stronghash":
      return functools.partial(
          string_ops.string_to_hash_bucket_strong, key=hasher_spec.key)
    raise ValueError("Unknown hasher %s" % hasher_spec.hasher)

  def lookup(self, keys, name=None):

    values = keys
    if self._num_oov_buckets == 0:
      ids = self._table.lookup(values, name=name)
    else:
      # TODO(yleon): Consider moving this functionality to its own kernel.
      with ops.name_scope(name, "%s_Lookup" % self.name) as scope:
        str_to_hash_bucket = self._get_string_to_hash_bucket_fn(
            self._hasher_spec)
        buckets = str_to_hash_bucket(
            _as_string(values),
            num_buckets=self._num_oov_buckets,
            name="hash_bucket")
        if self._table:
          ids = self._table.lookup(values)
          buckets = math_ops.add(buckets, self._table.size())
          is_id_non_default = math_ops.not_equal(ids, self._table.default_value)
          ids = array_ops.where(is_id_non_default, ids, buckets, name=scope)
        else:
          ids = buckets
    return ids

上面的lookup操作为核心代码，大致流程为：先将当前待查找的所有keys通过str_to_hash_bucket这个hash函数映射成int类型的bucket号，然后为了防止和已经在表中的那些index冲突，需要统一加上table.size()。然后在table中查找所有keys的index，如果在id table表中会返回正确的index，如果不在就返回默认值。然后将那些查找后等于默认值的keys的index换成通过hash函数得到的bucket号。这样存在的性能问题是当id table表较大时，会有很多时间浪费在没必要的hash操作上。所以一种优化方案是：先查表得到所有keys的index，然后只hash那些映射值等于默认值的元素。

我自己基于这个思路实现了一版，暂且就称为lookup_v2吧，但是虽然这样不用为所有的keys做hash，但也增加了几个操作，所以性能还不能保证。后续会考虑直接优化c++层面的代码。下面是核心代码：

 def lookup_v2(self, keys, name=None):

    values = keys
    if self._num_oov_buckets == 0:
       ids = self._table.lookup(values, name=name)
    else:
       with ops.name_scope(name, "%s_Lookup" % self.name) as scope:
          str_to_hash_bucket = self._get_string_to_hash_bucket_fn(
                    self._hasher_spec)
          if self._table:
              init_ids = self._table.lookup(values)
              is_id_default_idx = array_ops.where(math_ops.equal(init_ids, self._table.default_value))
              hash_values = array_ops.gather(values, array_ops.squeeze(is_id_default_idx))
              default_buckets = str_to_hash_bucket(
                        _as_string(hash_values),
                        num_buckets=self._num_oov_buckets,
                        name="hash_bucket")
              default_buckets = math_ops.add(default_buckets, self._table.size())
              default_buckets = control_flow_ops.cond(gen_math_ops.equal(array_ops.size(default_buckets), 1),
                                                            lambda: array_ops.expand_dims(default_buckets, axis=0),
                                                            lambda: default_buckets)
              ids = gen_array_ops.tensor_scatter_update(init_ids, is_id_default_idx, default_buckets)
          else:
              ids = str_to_hash_bucket(_as_string(values), num_buckets=self._num_oov_buckets, name="hash_bucket")
    return ids

参考文献：

https://mathmach.com/2442aa9e/
https://github.com/tensorflow/tensorflow/blob/5b900cfe4b3b848f577315a0dde09a729f770e95/tensorflow/python/ops/lookup_ops.py#L1042

本文转载自Alex-zhai知乎账号。

原文链接：https://zhuanlan.zhihu.com/p/93116229

创作场景

分布式 tensorflow 源码解读 3：lookup.index_table_from_tensor
