SIA-GateWay 之 API 网关安装部署指南

git clone https://github.com/siaorg/sia-gateway.git

.  ├── sia-gateway-admin-buildcomponent  网关admin组件集合  │   ├── sia-gateway-admin             网关admin监控系统组件  │   ├── sia-gateway-synchspeed        网关对下游服务实时感知组件  │   ├── sia-gateway-stream            网关日志组件  │   ├── sia-gateway-service           网关系统辅助组件  │   ├── sia-gateway-monitor           网关监控、日志组件  │   │    ├── sia-gateway-reactive      │   │    ├── sia-gateway-messaging    基础依赖   │   │    ├── sia-gateway-sink  │   │    ├── sia-gateway-esclient  │   │    ├── sia-gateway-base  ├── sia-gateway-admin-display         网关系统前端代码  ├── sia-gateway-buildcomponent        网关core-buildcomponent  │   ├── sia-gateway-core              网关Core节点  │   │   ├── sia-gateway-base  │   │   ├── sia-gateway-messaging     基础依赖  │   │   ├── sia-gateway-reactive  │   │   ├── sia-gateway-template

/sia-gateway/sia-gateway-admin/src/main/resources/db/gateway_admin.sql

\# 网关admin中心conf  /sia-gateway/sia-gateway-admin-buildcomponent/config/gateway_admin_test.yml
\# 网关监控服务conf  /sia-gateway/sia-gateway-admin-buildcomponent/config/gateway_monitor_test.yml
\# 网关辅助节点conf  /sia-gateway/sia-gateway-admin-buildcomponent/config/gateway_service_test.yml
\# 网关日志服务conf  /sia-gateway/sia-gateway-admin-buildcomponent/config/gateway_stream_test.yml
\# 网关实时感知服务conf  /sia-gateway/sia-gateway-admin-buildcomponent/config/gateway_synchspeed_test.yml
\# 网关核心节点conf  /sia-gateway/sia-gateway-buildcomponent/config/gateway_test.yml

    cd sia-gateway
    chmod +x *.sh
    sh build.sh

unzip gateway_admin_1.0.zip
cd /gatewayadmin/bin
chmod +x *.sh
\#启动网关管理服务，包括：admin、stream、service、synchspeed、monitor。  sh onekey_start.sh
---------------------------------------------------  unzip gateway_1.0.zip
cd /gateway/bin
chmod +x *.sh
\#启动网关Core服务  sh start_gateway_test.sh

+ nginx的代理配置，进入nginx的目录下nginx.conf，添加如下配置：
```conf      upstream apigateway.open.location1 {          \#### sia-gateway-admin服务IP        server *******:8090 ;       }      server {           \# nginx 监听端口          listen       18086;          server_name  localhost;          access_log  logs/host.access.log  main;          \#access_log  "pipe:rollback logs/host.access_log interval=1d baknum=7 maxsize=2G"  main;          location / {              \#root   html;              \#index  index.html index.htm;              root  /app/jar/ROOT/dist;              index  index.html index.htm;          }          \# 后端服务location           location ^~ /vv1/  {                  proxy_pass http://apigateway.open.location1/;                    proxy_set_header   Host  $host;                   proxy_set_header   X-Real-IP $http_x_forwarded_for;                   proxy_set_header   X-Forwarded-For  $proxy_add_x_forwarded_for;                   proxy_http_version 1.1;          }          error_page   500 502 503 504  /50xcn.html;          location = /50xcn.html {              root   html/error_page;              index 50xcn.html;          }          location /check_status {              vhost_traffic_status_display;              vhost_traffic_status_display_format json;          }      }  ```  + 重启nginx
```sh  \#校验配置是否正确  ./nginx -t
\# 重新启动  ./nginx -s reload
```

        /**           \* vmware部署： 127.0.0.1 ----> nginx的ip地址           \* docker镜像部署： 127.0.0.1 ----> docker容器的宿主机ip           \*/          'CESHI_API_HOST': '127.0.0.1:18086/vv1',
        /**           \* 127.0.0.1 ----> kibana的ip地址           \*/          'CESHI_API_HOST_LOG': '127.0.0.1:5601'

    \# 构建镜像      cd /sia-gateway/
    \# 授权      chmod +x *.sh
    \# 构建镜像      sh docker-build.sh
    \# 启动容器和服务      sh docker-run.sh
    \# 查看容器是否启动成功      docker ps
    \# 进入容器查看服务运行情况      docker exec -it gateway-test:v1 bash
