TiDB Operator实践

K8s 和 TiDB 都是目前开源社区中活跃的开源产品,TiDB Operator 项目是一个在 K8s 上编排管理 TiDB 集群的项目。本文详细记录了部署 K8s 及 install TiDB Operator 的详细实施过程,希望能对刚 " 入坑 " 的同学有所帮助。

一、环境

Ubuntu 16.04
K8s 1.14.1

二、Kubespray 安装 K8s

配置免密登录

复制代码
1yum -y install expect
  • vi /tmp/autocopy.exp
复制代码
1#!/usr/bin/expect
2
3set timeout
4set user_hostname [lindex $argv ]
5set password [lindex $argv ]
6spawn ssh-copy-id $user_hostname
7 expect {
8 "(yes/no)?"
9 {
10 send "yes\n"
11 expect "*assword:" { send "$password\n"}
12 }
13 "*assword:"
14 {
15 send "$password\n"
16 }
17 }
18expect eof
复制代码
1ssh-keyscan addedip >> ~/.ssh/known_hosts
2
3ssh-keygen -t rsa -P ''
4
5for i in 10.0.0.{31,32,33,40,10,2050}; do ssh-keyscan $i >> ~/.ssh/known_hosts ; done
6
7/tmp/autocopy.exp root@addeip
8ssh-copy-id addedip
9
10/tmp/autocopy.exp root@10.0.0.31
11/tmp/autocopy.exp root@10.0.0.32
12/tmp/autocopy.exp root@10.0.0.33
13/tmp/autocopy.exp root@10.0.0.40
14/tmp/autocopy.exp root@10.0.0.10
15/tmp/autocopy.exp root@10.0.0.20
16/tmp/autocopy.exp root@10.0.0.50

配置 Kubespray

复制代码
1pip install -r requirements.txt
2cp -rfp inventory/sample inventory/mycluster
  • inventory/mycluster/inventory.ini
  • inventory/mycluster/inventory.ini
复制代码
1# ## Configure 'ip' variable to bind kubernetes services on a
2# ## different ip than the default iface
3# ## We should set etcd_member_name for etcd cluster. The node that is not a etcd member do not need to set the value, or can set the empty string value.
4[all]
5# node1 ansible_host=95.54.0.12 # ip=10.3.0.1 etcd_member_name=etcd1
6# node2 ansible_host=95.54.0.13 # ip=10.3.0.2 etcd_member_name=etcd2
7# node3 ansible_host=95.54.0.14 # ip=10.3.0.3 etcd_member_name=etcd3
8# node4 ansible_host=95.54.0.15 # ip=10.3.0.4 etcd_member_name=etcd4
9# node5 ansible_host=95.54.0.16 # ip=10.3.0.5 etcd_member_name=etcd5
10# node6 ansible_host=95.54.0.17 # ip=10.3.0.6 etcd_member_name=etcd6
11etcd1 ansible_host=10.0.0.31 etcd_member_name=etcd1
12etcd2 ansible_host=10.0.0.32 etcd_member_name=etcd2
13etcd3 ansible_host=10.0.0.33 etcd_member_name=etcd3
14master1 ansible_host=10.0.0.40
15node1 ansible_host=10.0.0.10
16node2 ansible_host=10.0.0.20
17node3 ansible_host=10.0.0.50
18
19# ## configure a bastion host if your nodes are not directly reachable
20# bastion ansible_host=x.x.x.x ansible_user=some_user
21
22[kube-master]
23# node1
24# node2
25master1
26[etcd]
27# node1
28# node2
29# node3
30etcd1
31etcd2
32etcd3
33
34[kube-node]
35# node2
36# node3
37# node4
38# node5
39# node6
40node1
41node2
42node3
43
44[k8s-cluster:children]
45kube-master
46kube-node

节点所需镜像的文件

由于某些镜像国内无法访问需要现将镜像通过代理下载到本地然后上传到本地镜像仓库或 DockerHub,同时修改配置文件,个别组件存放位置 https://storage.googleapis.com,需要新建 Nginx 服务器分发文件。

建立 Nginx 服务器

  • ~/distribution/docker-compose.yml
  • 创建文件目录及 Nginx 配置文件目录
  • ~/distribution/conf.d/open_distribute.conf
  • 启动
  • 下载并上传所需文件 具体版本号参考 roles/download/defaults/main.yml 文件中 kubeadm_version、kube_version、image_arch 参数
  • 安装 Docker 及 Docker-Compose
复制代码
1apt-get install \
2apt-transport-https \
3ca-certificates \
4curl \
5gnupg-agent \
6software-properties-common
7
8curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -
9
10add-apt-repository \
11"deb [arch=amd64] https://download.docker.com/linux/ubuntu \
12$(lsb_release -cs) \
13stable"
14
15apt-get update
16
17apt-get install docker-ce docker-ce-cli containerd.io
18
19chmod +x /usr/local/bin/docker-compose
20sudo curl -L "https://github.com/docker/compose/releases/download/1.24.0/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
  • 新建 Nginx docker-compose.yml
复制代码
1mkdir ~/distribution
2vi ~/distribution/docker-compose.yml
复制代码
1# distribute
2version: '2'
3services:
4 distribute:
5 image: nginx:1.15.12
6 volumes:
7 - ./conf.d:/etc/nginx/conf.d
8 - ./distributedfiles:/usr/share/nginx/html
9 network_mode: "host"
10 container_name: nginx_distribute
复制代码
1mkdir ~/distribution/distributedfiles
2mkdir ~/distribution/
3mkdir ~/distribution/conf.d
4vi ~/distribution/conf.d/open_distribute.conf
复制代码
1#open_distribute.conf
2
3server {
4 #server_name distribute.search.leju.com;
5 listen 8888;
6
7 root /usr/share/nginx/html;
8
9 add_header Access-Control-Allow-Origin *;
10 add_header Access-Control-Allow-Headers X-Requested-With;
11 add_header Access-Control-Allow-Methods GET,POST,OPTIONS;
12
13 location / {
14 # index index.html;
15 autoindex on;
16 }
17 expires off;
18 location ~ .*\.(gif|jpg|jpeg|png|bmp|swf|eot|ttf|woff|woff2|svg)$ {
19 expires -1;
20 }
21
22 location ~ .*\.(js|css)?$ {
23 expires -1 ;
24 }
25} # end of public static files domain : [ distribute.search.leju.com ]
复制代码
1docker-compose up -d
复制代码
1wget https://storage.googleapis.com/kubernetes-release/release/v1.14.1/bin/linux/amd64/kubeadm
2
3scp /tmp/kubeadm 10.0.0.60:/root/distribution/distributedfiles
4
5wget https://storage.googleapis.com/kubernetes-release/release/v1.14.1/bin/linux/amd64/hyperkube
  • 需要下载并上传到私有仓库的镜像
复制代码
1docker pull k8s.gcr.io/cluster-proportional-autoscaler-amd64:1.4.0
2docker tag k8s.gcr.io/cluster-proportional-autoscaler-amd64:1.4.0 jiashiwen/cluster-proportional-autoscaler-amd64:1.4.0
3docker push jiashiwen/cluster-proportional-autoscaler-amd64:1.4.0
4
5docker pull k8s.gcr.io/k8s-dns-node-cache:1.15.1
6docker tag k8s.gcr.io/k8s-dns-node-cache:1.15.1 jiashiwen/k8s-dns-node-cache:1.15.1
7docker push jiashiwen/k8s-dns-node-cache:1.15.1
8
9docker pull gcr.io/google_containers/pause-amd64:3.1
10docker tag gcr.io/google_containers/pause-amd64:3.1 jiashiwen/pause-amd64:3.1
11docker push jiashiwen/pause-amd64:3.1
12
13docker pull gcr.io/google_containers/kubernetes-dashboard-amd64:v1.10.1
14docker tag gcr.io/google_containers/kubernetes-dashboard-amd64:v1.10.1 jiashiwen/kubernetes-dashboard-amd64:v1.10.1
15docker push jiashiwen/kubernetes-dashboard-amd64:v1.10.1
16
17docker pull gcr.io/google_containers/kube-apiserver:v1.14.1
18docker tag gcr.io/google_containers/kube-apiserver:v1.14.1 jiashiwen/kube-apiserver:v1.14.1
19docker push jiashiwen/kube-apiserver:v1.14.1
20
21docker pull gcr.io/google_containers/kube-controller-manager:v1.14.1
22docker tag gcr.io/google_containers/kube-controller-manager:v1.14.1 jiashiwen/kube-controller-manager:v1.14.1
23docker push jiashiwen/kube-controller-manager:v1.14.1
24
25docker pull gcr.io/google_containers/kube-scheduler:v1.14.1
26docker tag gcr.io/google_containers/kube-scheduler:v1.14.1 jiashiwen/kube-scheduler:v1.14.1
27docker push jiashiwen/kube-scheduler:v1.14.1
28
29docker pull gcr.io/google_containers/kube-proxy:v1.14.1
30docker tag gcr.io/google_containers/kube-proxy:v1.14.1 jiashiwen/kube-proxy:v1.14.1
31docker push jiashiwen/kube-proxy:v1.14.1
32
33docker pull gcr.io/google_containers/pause:3.1
34docker tag gcr.io/google_containers/pause:3.1 jiashiwen/pause:3.1
35docker push jiashiwen/pause:3.1
36
37docker pull gcr.io/google_containers/coredns:1.3.1
38docker tag gcr.io/google_containers/coredns:1.3.1 jiashiwen/coredns:1.3.1
39docker push jiashiwen/coredns:1.3.1
  • 用于下载上传镜像的脚本
复制代码
1#!/bin/bash
2
3privaterepo=jiashiwen
4
5k8sgcrimages=(
6cluster-proportional-autoscaler-amd64:1.4.0
7k8s-dns-node-cache:1.15.1
8)
9
10gcrimages=(
11pause-amd64:3.1
12kubernetes-dashboard-amd64:v1.10.1
13kube-apiserver:v1.14.1
14kube-controller-manager:v1.14.1
15kube-scheduler:v1.14.1
16kube-proxy:v1.14.1
17pause:3.1
18coredns:1.3.1
19)
20
21
22for k8sgcrimageName in ${k8sgcrimages[@]} ; do
23echo $k8sgcrimageName
24docker pull k8s.gcr.io/$k8sgcrimageName
25docker tag k8s.gcr.io/$k8sgcrimageName $privaterepo/$k8sgcrimageName
26docker push $privaterepo/$k8sgcrimageName
27done
28
29
30for gcrimageName in ${gcrimages[@]} ; do
31echo $gcrimageName
32docker pull gcr.io/google_containers/$gcrimageName
33docker tag gcr.io/google_containers/$gcrimageName $privaterepo/$gcrimageName
34docker push $privaterepo/$gcrimageName
35done
  • 修改文件 inventory/mycluster/group_vars/k8s-cluster/k8s-cluster.yml,修改 K8s 镜像仓库
复制代码
1# kube_image_repo: "gcr.io/google-containers"
2kube_image_repo: "jiashiwen"
  • 修改 roles/download/defaults/main.yml
复制代码
1#dnsautoscaler_image_repo: "k8s.gcr.io/cluster-proportional-autoscaler-{{ image_arch }}"
2dnsautoscaler_image_repo: "jiashiwen/cluster-proportional-autoscaler-{{ image_arch }}"
3
4#kube_image_repo: "gcr.io/google-containers"
5kube_image_repo: "jiashiwen"
6
7#pod_infra_image_repo: "gcr.io/google_containers/pause-{{ image_arch }}"
8pod_infra_image_repo: "jiashiwen/pause-{{ image_arch }}"
9
10#dashboard_image_repo: "gcr.io/google_containers/kubernetes-dashboard-{{ image_arch }}"
11dashboard_image_repo: "jiashiwen/kubernetes-dashboard-{{ image_arch }}"
12
13#nodelocaldns_image_repo: "k8s.gcr.io/k8s-dns-node-cache"
14nodelocaldns_image_repo: "jiashiwen/k8s-dns-node-cache"
15
16#kubeadm_download_url: "https://storage.googleapis.com/kubernetes-release/ release/{{ kubeadm_version }}/bin/linux/{{ image_arch }}/kubeadm"
17kubeadm_download_url: "http://10.0.0.60:8888/kubeadm"
18
19#hyperkube_download_url: "https://storage.googleapis.com/ kubernetes-release/release/{{ kube_version }}/bin/linux/{{ image_arch }}/ hyperkube"
20hyperkube_download_url: "http://10.0.0.60:8888/hyperkube"

三、执行安装

  • 安装命令
复制代码
1ansible-playbook -i inventory/mycluster/inventory.ini cluster.yml
  • 重置命令
复制代码
1ansible-playbook -i inventory/mycluster/inventory.ini reset.yml

四、验证 K8s 集群

安装 Kubectl

  • 本地浏览器打开得到最新版本为 v1.14.1

  • 用上一步得到的最新版本号 v1.7.1 替换下载地址中的 $(curl -s 下载地址) 得到真正的下载地址

  • 上传下载好的 kubectl

复制代码
1scp /tmp/kubectl root@xxx:/root
  • 修改属性
复制代码
1chmod +x ./kubectl
2mv ./kubectl /usr/local/bin/kubectl
  • Ubuntu
复制代码
1sudo snap install kubectl --classic
  • CentOS

将 master 节点上的~/.kube/config 文件复制到你需要访问集群的客户端上即可

复制代码
1scp 10.0.0.40:/root/.kube/config ~/.kube/config

执行命令验证集群

复制代码
1kubectl get nodes
2kubectl cluster-info

五、TiDB-Operaor 部署

安装 helm

  • 安装 helm
复制代码
1curl https://raw.githubusercontent.com/helm/helm/master/scripts/get > get_helm.sh
2chmod 700 get_helm.sh
3./get_helm.sh
  • 查看 helm 版本
复制代码
1helm version
  • 初始化
复制代码
1helm init --upgrade -i registry.cn-hangzhou.aliyuncs.com/google_containers/tiller:v2.13.1 --stable-repo-url https://kubernetes.os

为 K8s 提供 local volumes

  • 参考文档
    tidb-operator 启动会为 pd 和 tikv 绑定 pv,需要在 discovery directory 下创建多个目录
  • 格式化并挂载磁盘
复制代码
1mkfs.ext4 /dev/vdb
2DISK_UUID=$(blkid -s UUID -o value /dev/vdb)
3mkdir /mnt/$DISK_UUID
4mount -t ext4 /dev/vdb /mnt/$DISK_UUID
  • /etc/fstab 持久化 mount
复制代码
1echo UUID=`sudo blkid -s UUID -o value /dev/vdb` /mnt/$DISK_UUID ext4 defaults 0 2 | sudo tee -a /etc/fstab
  • 创建多个目录并 mount 到 discovery directory
复制代码
1for i in $(seq 1 10); do
2sudo mkdir -p /mnt/${DISK_UUID}/vol${i} /mnt/disks/${DISK_UUID}_vol${i}
3sudo mount --bind /mnt/${DISK_UUID}/vol${i} /mnt/disks/${DISK_UUID}_vol${i}
4done
  • /etc/fstab 持久化 mount
复制代码
1for i in $(seq 1 10); do
2echo /mnt/${DISK_UUID}/vol${i} /mnt/disks/${DISK_UUID}_vol${i} none bind 0 0 | sudo tee -a /etc/fstab
3done
  • 为 tidb-operator 创建 local-volume-provisioner
复制代码
1$ kubectl apply -f https://raw.githubusercontent.com/pingcap/tidb-operator/master/manifests/local-dind/local-volume-provisioner.yaml
2$ kubectl get po -n kube-system -l app=local-volume-provisioner
3$ kubectl get pv --all-namespaces | grep local-storage

六、Install TiDB Operator

项目中使用了 gcr. io/google-containers/hyperkube,国内访问不了,简单的办法是把镜像重新 push 到 dockerhub 然后修改 charts/tidb-operator/values.yaml

复制代码
1scheduler:
2 # With rbac.create=false, the user is responsible for creating this account
3 # With rbac.create=true, this service account will be created
4 # Also see rbac.create and clusterScoped
5 serviceAccount: tidb-scheduler
6 logLevel: 2
7 replicas: 1
8 schedulerName: tidb-scheduler
9 resources:
10 limits:
11 cpu: 250m
12 memory: 150Mi
13 requests:
14 cpu: 80m
15 memory: 50Mi
16 # kubeSchedulerImageName: gcr.io/google-containers/hyperkube
17 kubeSchedulerImageName: yourrepo/hyperkube
18 # This will default to matching your kubernetes version
19 # kubeSchedulerImageTag: latest
  • TiDB Operator 使用 CRD 扩展 Kubernetes,因此要使用 TiDB Operator,首先应该创建 TidbCluster 自定义资源类型。
复制代码
1kubectl apply -f https://raw.githubusercontent.com/pingcap/tidb-operator/master/manifests/crd.yaml
2kubectl get crd tidbclusters.pingcap.com
  • 安装 TiDB-Operator
复制代码
1$ git clone https://github.com/pingcap/tidb-operator.git
2$ cd tidb-operator
3$ helm install charts/tidb-operator --name=tidb-operator --namespace=tidb-admin
4$ kubectl get pods --namespace tidb-admin -l app.kubernetes.io/ instance=tidb-operator

七、部署 TiDB

复制代码
1helm install charts/tidb-cluster --name=demo --namespace=tidb
2watch kubectl get pods --namespace tidb -l app.kubernetes.io/instance=demo -o wide

八、验证

安装 MySQL 客户端

复制代码
1wget https://dev.mysql.com/get/mysql80-community-release-el7-3.noarch.rpm
2yum localinstall mysql80-community-release-el7-3.noarch.rpm -y
3yum repolist all | grep mysql
4yum-config-manager --disable mysql80-community
5yum-config-manager --enable mysql57-community
6yum install mysql-community-client
  • Ubuntu 安装
复制代码
1wget https://dev.mysql.com/get/mysql-apt-config_0.8.13-1_all.deb
2dpkg -i mysql-apt-config_0.8.13-1_all.deb
3apt update
4
5# 选择 MySQL 版本
6dpkg-reconfigure mysql-apt-config
7apt install mysql-client -y

九、映射 TiDB 端口

  • 查看 TiDB Service
复制代码
1kubectl get svc --all-namespaces
  • 映射 TiDB 端口
复制代码
1# 仅本地访问
2kubectl port-forward svc/demo-tidb 4000:4000 --namespace=tidb
3
4# 其他主机访问
5kubectl port-forward --address 0.0.0.0 svc/demo-tidb 4000:4000 --namespace=tidb
  • 首次登录 MySQL
复制代码
1mysql -h 127.0.0.1 -P 4000 -u root -D test
  • 修改 TiDB 密码
复制代码
1SET PASSWORD FOR 'root'@'%' = 'wD3cLpyO5M'; FLUSH PRIVILEGES;

评论

发布
