GaussDB T 1.0.2 一主一备集群部署实战

本文由 dbaplus 社群授权转载。

GaussDB T 1.0.2 版本已经发布了,此版本为 GA 版本,相比 1.0.1 版本稳定性和功能方面做了加强,华为后续也将要推出 RAC 版本。本文主要介绍当前 GA 版本下的主备集群方式安装。

主备(一主一备)部署方案无 CN,其中 DN 主机所在的节点为主节点,对外提供业务。

GaussDB T 1.0.2 一主一备集群部署实战

集群中各组件功能:

  • CM:集群管理模块(ClusterManager)。管理和监控分布式系统中各个功能单元和物理资源的运行状况,确保整个系统的稳定运行。
  • DN:数据节点(Datanode)。负责存储业务数据,执行数据查询任务以及返回执行结果。
  • ETCD:高可用分布式键值 (key-value) 数据库。负责存储集群各个节点和实例集群状态,便于集群 CM 管理各个实例。
  • Storage:服务器的本地存储资源,持久化存储数据。

一、环境准备

  • 操作系统:CentOS Linux release 7.5.1804 (Core)
  • 数据库软件:GaussDB_T_1.0.2-CLUSTER-CentOS-64bit.tar.gz

GaussDB T 1.0.2 一主一备集群部署实战

二、安装步骤

1、root 远程登录权限修改(两个节点均需操作)

复制代码
sed -i 's/#PermitRootLogin yes/PermitRootLogin yes/g' /etc/ssh/sshd_config
sed -i 's/#PasswordAuthentication yes/ PasswordAuthentication yes/g' /etc/ssh/sshd_config

修改完重启 sshd 服务:

复制代码
/bin/systemctl restart sshd.service

2、关闭防火墙和 SELinux(两个节点均需操作)

复制代码
systemctl stop firewalld.service
systemctl disable firewalld.service
sed -i 's/SELINUX=enforcing/SELINUX=disabled/g' /etc/selinux/config

3、配置 corefile(两个节点均需操作)

复制代码
echo 'ulimit -c unlimited'>>/etc/profile
echo 'kernel.core_pattern =/opt/gdb/corefile/core-%e-%p-%t'>>/etc/sysctl.conf

使配置生效:

复制代码
source /etc/profile
sysctl -p

4、检查 ntp 和 lsof(两个节点均需操作)

复制代码
rpm -qa|grep ntp

若没有,使用 yum 安装 ntp:

复制代码
yum install ntp
which lsof

若没有,使用 yum 安装 lsof:

复制代码
yum install lsof

5、创建数据库安装用户组和用户(两个节点均需操作)

复制代码
groupadd dbgrp
useradd -g dbgrp -d /home/omm -m -s /bin/bash omm

设置密码:

复制代码
passwd omm

6、创建存放软件包的目录 /opt/software/gaussdb 并上传安装包

复制代码
mkdir -p /opt/software/gaussdb
[root@gauss1 gaussdb]# tar -zxvf GaussDB_T_1.0.2-CENTOS7.5-X86.tar.gz
[root@gauss1 gaussdb]# tar -zxvf GaussDB_T_1.0.2-CLUSTER-CentOS-64bit.tar.gz
[root@gauss1 gaussdb]# chmod 755 /opt/software/
[root@gauss1 gaussdb]# chmod -R 755 /opt/software/gaussdb/

7、从 /opt/software/gaussdb/template 获取预置的配置文件,根据实际部署需求修改配置

复制代码
[root@gauss1 ~]# vi /opt/software/gaussdb/clusterconfig.xml
<?xml version="1.0" encoding="UTF-8"?>
<ROOT>
<!-- -->
<CLUSTER>
<PARAM name="clusterName" value="GaussDB_100"/>
<PARAM name="nodeNames" value="gauss1,gauss2"/>
<PARAM name="gaussdbAppPath" value="/opt/gaussdb/app"/>
<PARAM name="gaussdbLogPath" value="/opt/gaussdb/log/"/>
<PARAM name="tmpMppdbPath" value="/opt/gaussdb/tmp/gaussdb_mppdb"/>
<PARAM name="gaussdbToolPath" value="/opt/gaussdb/huawei/wisequery"/>
<PARAM name="datanodeType" value="DN_ZENITH_HA"/>
<PARAM name="coordinatorType" value="CN_ZENITH_ZSHARDING"/>
<PARAM name="replicationCount" value="2"/>
<PARAM name="clusterType" value="mutil-AZ"/>
<!-- HA2 -->
<PARAM name="Ha2Node" value="true"/>
<PARAM name="GatewayIP" value="192.168.238.2"/>
<PARAM name="CMAgentPingTryTime" value="3"/>
<PARAM name="CMAgentPingInterval" value="5"/>
<!--floatip-->
<PARAM name="ServiceType" value="SingleService"/>
</CLUSTER>
<!-- -->
<DEVICELIST>
<!-- plat1 -->
<DEVICE sn="1000001">
<PARAM name="name" value="gauss1"/>
<PARAM name="azName" value="AZ1"/>
<PARAM name="azPriority" value="1"/>
<!-- IP -->
<PARAM name="backIp1" value="192.168.238.130"/>
<PARAM name="sshIp1" value="192.168.238.130"/>
<PARAM name="agentlsnPort" value="7020"/>
<!-- GTS -->
<!-- ETCD -->
<PARAM name="etcdNum" value="2"/>
<PARAM name="etcdListenPort" value="22100"/>
<PARAM name="etcdHaPort" value="22200"/>
<PARAM name="etcdListenIp1" value="192.168.238.130"/>
<PARAM name="etcdHaIp1" value="192.168.238.130"/>
<PARAM name="etcdDir1" value="/opt/gaussdb/data/data_etcd"/>
<PARAM name="etcdDir2" value="/opt/gaussdb/data/data_etcd1"/>
<!--cn-->
<!-- dn -->
<PARAM name="dataNum" value="1"/>
<PARAM name="dataPortBase" value="15402"/>
<PARAM name="dataNode1" value="/opt/gaussdb/data/data_dn1,gauss2,/opt/gaussdb/data/data_dn1"/>
</DEVICE>
<!-- plat2 -->
<DEVICE sn="1000002">
<PARAM name="name" value="gauss2"/>
<PARAM name="azName" value="AZ1"/>
<PARAM name="azPriority" value="1"/>
<!--IP -->
<PARAM name="backIp1" value="192.168.238.131"/>
<PARAM name="sshIp1" value="192.168.238.131"/>
<PARAM name="agentlsnPort" value="7020"/>
<!-- ETCD -->
<PARAM name="etcdNum" value="1"/>
<PARAM name="etcdListenPort" value="22100"/>
<PARAM name="etcdHaPort" value="22200"/>
<PARAM name="etcdListenIp1" value="192.168.238.131"/>
<PARAM name="etcdHaIp1" value="192.168.238.131"/>
<PARAM name="etcdDir1" value="/opt/gaussdb/data/data_etcd"/>
<!--cn-->
<!-- dn -->
<!-- cm -->
<PARAM name="cmsNum" value="1"/>
<PARAM name="cmServerPortBase" value="21900"/>
<PARAM name="cmServerListenIp1" value="192.168.238.131,192.168.238.130"/>
<PARAM name="cmServerHaIp1" value="192.168.238.131,192.168.238.130"/>
<PARAM name="cmServerlevel" value="1"/>
<PARAM name="cmServerRelation" value="gauss2,gauss1"/>
</DEVICE>
</DEVICELIST>
</ROOT>

8、安装 python3.7(如果环境已安装请忽略)

安装依赖包:

复制代码
yum -y groupinstall "Development tools"
yum -y install zlib-devel bzip2-devel openssl-devel ncurses-devel sqlite-devel readline-devel tk-devel gdbm-devel db4-devel libpcap-devel xz-devel
yum install libffi-devel -y
yum install -y gcc

下载 python3 安装包:

复制代码
cd /root
wget https://www.python.org/ftp/python/3.7.0/Python-3.7.0.tar.xz
tar -xvJf Python-3.7.0.tar.xz

编译安装:

复制代码
mkdir /usr/local/python3 #创建编译安装目录
cd Python-3.7.0
./configure --prefix=/usr/local/python3
make && make install

创建软连接:

复制代码
ln -s /usr/local/python3/bin/python3 /usr/local/bin/python3

验证下安装:

复制代码
python3 -V
pip3 –V

9、执行 gs_preinstall 准备环境

复制代码
[root@gauss1 gaussdb]# cd /opt/software/gaussdb/script/
[root@gauss1 script]# ./gs_preinstall -U omm -G dbgrp –X /opt/software/gaussdb/clusterconfig.xml

GaussDB T 1.0.2 一主一备集群部署实战

GaussDB T 1.0.2 一主一备集群部署实战

10、检测集群时间一致性

复制代码
[root@gauss1 script]# ./gs_checkos -i B -h gauss1,gauss2 -X /opt/software/gaussdb/clusterconfig.xml

GaussDB T 1.0.2 一主一备集群部署实战

11、执行安装脚本

复制代码
[root@gauss1 script]# su - omm
[omm@gauss1 ~]$ gs_install -X /opt/software/gaussdb/clusterconfig.xml

GaussDB T 1.0.2 一主一备集群部署实战

12、检查集群状态

GaussDB T 1.0.2 一主一备集群部署实战

安装完成!

三、安装过程中报错处理

1、执行./gs_preinstall 报 GAUSS-50204

复制代码
[root@gauss1 script]# ./gs_preinstall -U omm -G dbgrp -X /opt/software/gaussdb/clusterconfig.xml
[GAUSS-50204] : Failed to read cmServerRelation. The first item of cmServerRelation must be nodename.

解决:修改 clusterconfig.xml 文件中 cmServerRelation 值为 gauss2,gauss1 与 nodeNames 值对应。

2、执行./gs_preinstall 报 GAUSS-53011

复制代码
[root@gauss1 script]# ./gs_preinstall -U omm -G dbgrp -X /opt/software/gaussdb/clusterconfig.xml
Parsing the configuration file.
Successfully parsed the configuration file.
Installing the tools on the local node.
Successfully installed the tools on the local node.
Are you sure you want to create trust for root (yes/no)? yes
Please enter password for root.
Password:
Creating SSH trust for the root permission user.
Successfully created SSH trust for the root permission user.
All host RAM is consistent
Distributing package.
Successfully distributed package.
Are you sure you want to create the user[omm] and create trust for it (yes/no)? yes
Installing the tools in the cluster.
Successfully installed the tools in the cluster.
Checking system resource.
[FAILURE] gauss1:
[GAUSS-53011] : Failed to check gatewayIP [192.168.238.10]. Please check gatewayIP config is vaild in your environment.
[FAILURE] gauss2:
[GAUSS-53011] : Failed to check gatewayIP [192.168.238.10]. Please check gatewayIP config is vaild in your environment.

解决:修改 clusterconfig.xml 文件中 GatewayIP 为虚拟机网关地址 192.168.238.2。

3、检测集群时间一致性有警告

复制代码
[root@gauss1 script]# ./gs_checkos -i A12 -h gauss1,gauss2 -X /opt/software/gaussdb/clusterconfig.xml --detail
Root permission user has not SSH trust, create it when do checkos in remote node.
Creating SSH trust for the root permission user.
Please enter password for root.
Password:
Successfully creating SSH trust for the root permission user.
Checking items
A12.[ Time consistency status ] : Warning
[gauss1]
The current system time = (2020-03-06 16:37:43")
[gauss2]
The current system time = (2020-03-06 16:37:45")
Total numbers:1. Abnormal numbers:0. Warning numbers:1.
Clean SSH trust for the root permission user.
Successfully clean SSH trust for the root permission user.

解决:重新同步系统时间。

复制代码
[root@gauss1 ~]# cd /opt/software/gaussdb/script
[root@gauss1 script]# ./gs_checkos -i C1 -h gauss1,gauss2 -X /opt/software/gaussdb/clusterconfig.xml
Root permission user has not SSH trust, create it when do checkos in remote node.
Creating SSH trust for the root permission user.
Please enter password for root.
Password:
Successfully creating SSH trust for the root permission user.
C1. [ Set NTP Service ] : Normal
NOTICE: MTU value and some warning items can NOT be set. Please do it manually.
Total numbers:1. Abnormal numbers:0. Warning numbers:0.
Clean SSH trust for the root permission user.
Successfully clean SSH trust for the root permission user.

四、集群卸载

1、omm 用户执行 gs_uninstall --delete-data -X

复制代码
/opt/software/gaussdb/clusterconfig.xml
[omm@gauss1 ~]$ gs_uninstall --delete-data -X /opt/software/gaussdb/clusterconfig.xml
The data will be deleted and cannot be recovered. Are you sure you want to uninstall the cluster(yes/no)?yes
Check preinstall on every node.
Successfully checked preinstall on every node.
Stop cluster.
Check logfile path.
Clean crontab.
Clean crontab successfully.
Kill process for components.
Kill process for components successfully.
Uninstall components
Uninstall components successfully.
Modifying user's environmental variable.
Successfully modified user's environmental variable.
Clean tmp files and logs.
Successfully clean cluster's tmp and logs.
Successful uninstallation

2、清理主机的环境

复制代码
[root@gauss1 script]# ./gs_postuninstall -U omm -X /opt/software/gaussdb/clusterconfig.xml
The environment will be cleaned up and cannot be recovered.Are you sure you want to clean up the environment(yes/no)?yes
Parsing the configuration file.
Successfully parsed the configuration file.
Checking unpreinstallation.
Success checking unpreinstallation.
Deleting the instance paths.
Deleting the instance paths successfully.
Clean log and dependency.
Clean up the user environment variables
Clean up the user environment variable successfully
Clean up the remote system tool environment variables
Clean up the remote system tool environment variable successfully
Clean up the local system tool environment variables
Clean up the local system tool environment variable successfully
Clean log and dependency successfully.
Postuninstall successfully.
Please close the terminal and login again, ensure that the environment variable takes effect.

作者介绍

刘滨,中移信息数据库运维专家。拥有 Oracle OCP、OCM 认证,曾多年在银行金融保险行业一线运维,目前正在积极参与国产数据库的研究以及在移动场景下的推广等工作。
