Apache ShardingSphere 是一套开源的分布式数据库中间件解决方案组成的生态圈，它由 JDBC、Proxy 和 Sidecar（规划中）这 3 款相互独立，却又能够混合部署配合使用的产品组成。它们均提供标准化的数据分片、分布式事务和数据库治理功能，可适用于如 Java 同构、异构语言、云原生等各种多样化的应用场景。
ShardingSphere 已于 2020 年 4 月 16 日成为 Apache 软件基金会的顶级项目。
Narayana 简单介绍
Narayana（https://narayana.io/），是由 Jboss 团队提供的 XA 分布式事务的解决方案。
它具有以下特点：
标准的基于 JTA 实现。
TransactionManager(TM) 完全去中心化设计，与业务耦合，无需单独部署。
事务日志支持数据库存储，支持集群模式下的事务恢复。
ShardingTransactionManager 初始化 XATransactionDataSource 流程
ShardingSphere 对 XA 的支持提供一整套的 SPI 接口，在初始化话的时候，根据事务类型，先进行 TransactionManager 的初始化。我们先进入org.apache.shardingsphere.transaction.xa.XAShardingTransactionManager。代码如下:
private final Map<String, XATransactionDataSource> cachedDataSources = new HashMap<>(); private final XATransactionManager xaTransactionManager = XATransactionManagerLoader.getInstance().getTransactionManager(); @Override public void init(final DatabaseType databaseType, final Collection<ResourceDataSource> resourceDataSources) { for (ResourceDataSource each : resourceDataSources) { cachedDataSources.put(each.getOriginalName(), new XATransactionDataSource(databaseType, each.getUniqueResourceName(), each.getDataSource(), xaTransactionManager)); } // Narayana的初始化 xaTransactionManager.init(); }首先会根据配置的 datasource 将其转换成 XATransactionDataSource，具体代码在
new XATransactionDataSource(databaseType, each.getUniqueResourceName(), each.getDataSource(), xaTransactionManager))。我们跟进去，代码如下:
public XATransactionDataSource(final DatabaseType databaseType, final String resourceName, final DataSource dataSource, final XATransactionManager xaTransactionManager) { this.databaseType = databaseType; this.resourceName = resourceName; this.dataSource = dataSource; if (!CONTAINER_DATASOURCE_NAMES.contains(dataSource.getClass().getSimpleName())) { // 重点关注 1 ,返回了xaDatasource xaDataSource = XADataSourceFactory.build(databaseType, dataSource); this.xaTransactionManager = xaTransactionManager; // 重点关注2 注册资源 xaTransactionManager.registerRecoveryResource(resourceName, xaDataSource); } }我们重点来关注
XADataSourceFactory.build(databaseType, dataSource)，从名字我们就可以看出，这应该是返回JTA规范里面的XADataSource,在 ShardingSphere 里面很多的功能，可以从代码风格的命名上就能猜出来，这就是优雅代码（吹一波）。不多逼逼，我们进入该方法。
public final class XADataSourceFactory { public static XADataSource build(final DatabaseType databaseType, final DataSource dataSource) { return new DataSourceSwapper(XADataSourceDefinitionFactory.getXADataSourceDefinition(databaseType)).swap(dataSource); }}首先又是一个 SPI 定义的
XADataSourceDefinitionFactory，它根据不同的数据库类型，来加载不同的方言。然后我们进入swap方法。
public XADataSource swap(final DataSource dataSource) { XADataSource result = createXADataSource(); setProperties(result, getDatabaseAccessConfiguration(dataSource)); return result; }很简明，第一步创建，
XADataSource,第二步给它设置属性（包含数据的连接，用户名密码等），然后返回。
Narayana 初始化过程详解
我们首先进入org.apache.shardingsphere.transaction.xa.narayana.manager.NarayanaXATransactionManager
public final class NarayanaXATransactionManager implements XATransactionManager { //加载transactionManger private final TransactionManager transactionManager = jtaPropertyManager.getJTAEnvironmentBean().getTransactionManager();//获取事务恢复模块 private final XARecoveryModule xaRecoveryModule = XARecoveryModule.getRegisteredXARecoveryModule(); private final RecoveryManagerService recoveryManagerService = new RecoveryManagerService(); @Override public void init() { RecoveryManager.delayRecoveryManagerThread(); recoveryManagerService.create();//开启事务恢复 recoveryManagerService.start(); } @Override public void registerRecoveryResource(final String dataSourceName, final XADataSource xaDataSource) { xaRecoveryModule.addXAResourceRecoveryHelper(new DataSourceXAResourceRecoveryHelper(xaDataSource)); } @Override public void removeRecoveryResource(final String dataSourceName, final XADataSource xaDataSource) { xaRecoveryModule.removeXAResourceRecoveryHelper(new DataSourceXAResourceRecoveryHelper(xaDataSource)); } @SneakyThrows({SystemException.class, RollbackException.class}) @Override public void enlistResource(final SingleXAResource singleXAResource) { transactionManager.getTransaction().enlistResource(singleXAResource.getDelegate()); } @Override public TransactionManager getTransactionManager() { return transactionManager; } @Override public void close() throws Exception { recoveryManagerService.stop(); recoveryManagerService.destroy(); }}首先我们关注
jtaPropertyManager.getJTAEnvironmentBean().getTransactionManager()获取 TransactionManager，这是整个 Narayana 初始化的核心。进入代码com.arjuna.common.internal.util.propertyservice.BeanPopulator.getNamedInstance()。
private static <T> T getNamedInstance(Class<T> beanClass, String name, Properties properties) throws RuntimeException { StringBuilder sb = new StringBuilder().append(beanClass.getName()); if (name != null) sb.append(":").append(name); String key = sb.toString(); // we don't mind sometimes instantiating the bean multiple times, // as long as the duplicates never escape into the outside world. if(!beanInstances.containsKey(key)) { T bean = null; try { // 初始化 JTAEnvironmentBean 这个类 bean = beanClass.newInstance(); if (properties != null) { configureFromProperties(bean, name, properties); } else { //初始化属性配置 Properties defaultProperties = PropertiesFactory.getDefaultProperties(); configureFromProperties(bean, name, defaultProperties); } } catch (Throwable e) { throw new RuntimeException(e); } beanInstances.putIfAbsent(key, bean); } return (T) beanInstances.get(key); }我们重点关注
Properties defaultProperties = PropertiesFactory.getDefaultProperties();。最后会进入com.arjuna.common.util.propertyservice.AbstractPropertiesFactory.getPropertiesFromFile()。
public Properties getPropertiesFromFile(String propertyFileName, ClassLoader classLoader) { String propertiesSourceUri = null; try { // 文件名称为：jbossts-properties.xml 加载顺序为：This is the point where the search path is applied - user.dir (pwd), user.home, java.home, classpath propertiesSourceUri = com.arjuna.common.util.propertyservice.FileLocator.locateFile(propertyFileName, classLoader); } catch(FileNotFoundException fileNotFoundException) { // try falling back to a default file built into the .jar // Note the default- prefix on the name, to avoid finding it from the .jar at the previous stage // in cases where the .jar comes before the etc dir on the classpath. URL url = AbstractPropertiesFactory.class.getResource("/default-"+propertyFileName); if(url == null) { commonLogger.i18NLogger.warn_could_not_find_config_file(url); } else { propertiesSourceUri = url.toString(); } } catch (IOException e) { throw new RuntimeException("invalid property file "+propertiesSourceUri, e); } Properties properties = null; try { if (propertiesSourceUri != null) { //加载配置文件 properties = loadFromFile(propertiesSourceUri); } // 叠加系统配置属性 properties = applySystemProperties(properties); } catch(Exception e) { throw new RuntimeException("unable to load properties from "+propertiesSourceUri, e); } return properties; }加载文件名称为
jbossts-properties.xml, 加载路径优先级别为 ：user.dir > user.home >java.home >classpath。最后再叠加上系统属性，然后返回。
我们再来看一下 jbossts-properties.xml 的参考格式如下:
<properties> <entry key="CoordinatorEnvironmentBean.commitOnePhase">YES</entry> <entry key="ObjectStoreEnvironmentBean.objectStoreType">com.arjuna.ats.internal.arjuna.objectstore.jdbc.JDBCStore</entry> <entry key="ObjectStoreEnvironmentBean.jdbcAccess">com.arjuna.ats.internal.arjuna.objectstore.jdbc.accessors.DynamicDataSourceJDBCAccess;ClassName=com.mysql.jdbc.jdbc2.optional.MysqlDataSource;DatabaseName=jbossts;ServerName=172.25.4.62;PortNumber=3306;User=j_jbossts;Password=9MfNHoRncCi8</entry> <entry key="ObjectStoreEnvironmentBean.tablePrefix">Action</entry> <entry key="ObjectStoreEnvironmentBean.dropTable">true</entry> <entry key="ObjectStoreEnvironmentBean.stateStore.objectStoreType">com.arjuna.ats.internal.arjuna.objectstore.jdbc.JDBCStore</entry> <entry key="ObjectStoreEnvironmentBean.stateStore.jdbcAccess">com.arjuna.ats.internal.arjuna.objectstore.jdbc.accessors.DynamicDataSourceJDBCAccess;ClassName=com.mysql.jdbc.jdbc2.optional.MysqlDataSource;DatabaseName=jbossts;ServerName=172.25.4.62;PortNumber=3306;User=j_jbossts;Password=9MfNHoRncCi8</entry> <entry key="ObjectStoreEnvironmentBean.stateStore.tablePrefix">stateStore</entry> <entry key="ObjectStoreEnvironmentBean.stateStore.dropTable">true</entry> <entry key="ObjectStoreEnvironmentBean.communicationStore.objectStoreType">com.arjuna.ats.internal.arjuna.objectstore.jdbc.JDBCStore</entry> <entry key="ObjectStoreEnvironmentBean.communicationStore.jdbcAccess">com.arjuna.ats.internal.arjuna.objectstore.jdbc.accessors.DynamicDataSourceJDBCAccess;ClassName=com.mysql.jdbc.jdbc2.optional.MysqlDataSource;DatabaseName=jbossts;ServerName=172.25.4.62;PortNumber=3306;User=j_jbossts;Password=9MfNHoRncCi8</entry> <entry key="ObjectStoreEnvironmentBean.communicationStore.tablePrefix">Communication</entry> <entry key="ObjectStoreEnvironmentBean.communicationStore.dropTable">true</entry> <entry key="ObjectStoreEnvironmentBean.transactionSync">ON</entry> <entry key="CoreEnvironmentBean.nodeIdentifier">1</entry> <entry key="JTAEnvironmentBean.xaRecoveryNodes">1</entry> <entry key="JTAEnvironmentBean.xaResourceOrphanFilterClassNames"> com.arjuna.ats.internal.jta.recovery.arjunacore.JTATransactionLogXAResourceOrphanFilter com.arjuna.ats.internal.jta.recovery.arjunacore.JTANodeNameXAResourceOrphanFilter com.arjuna.ats.internal.jta.recovery.arjunacore.JTAActionStatusServiceXAResourceOrphanFilter </entry> <entry key="CoreEnvironmentBean.socketProcessIdPort">0</entry> <entry key="RecoveryEnvironmentBean.recoveryModuleClassNames"> com.arjuna.ats.internal.arjuna.recovery.AtomicActionRecoveryModule com.arjuna.ats.internal.jta.recovery.arjunacore.XARecoveryModule </entry> <entry key="RecoveryEnvironmentBean.expiryScannerClassNames"> com.arjuna.ats.internal.arjuna.recovery.ExpiredTransactionStatusManagerScanner </entry> <entry key="RecoveryEnvironmentBean.recoveryPort">4712</entry> <entry key="RecoveryEnvironmentBean.recoveryAddress"></entry> <entry key="RecoveryEnvironmentBean.transactionStatusManagerPort">0</entry> <entry key="RecoveryEnvironmentBean.transactionStatusManagerAddress"></entry> <entry key="RecoveryEnvironmentBean.recoveryListener">NO</entry> <entry key="RecoveryEnvironmentBean.recoveryBackoffPeriod">1</entry></properties>它被视为标准 java.util.Properties 文件的 XML 格式并按需加载。entry 名称的形式为：类名.属性名。提供的配置类都在com.arjuna.ats.arjuna.common包下，以 bean 结尾的实体类。
文件加载后，它会被缓存，直到 JVM 重新启动才重新读取。对属性文件的更改需要重新启动才能生效
在属性加载之后，将检查 EnvironmentBean，对于每个字段，如果属性在搜索顺序中包含如下匹配的键，则使用属性的值调用该字段的 setter 方法，或者使用不同的系统属性调用该字段的 setter 方法。
然后将 bean 返回给调用者，调用者可以通过调用 setter 方法进一步覆盖值。
我们返回主线：现在已经加载了配置。接下来就是执行configureFromProperties(bean, name, defaultProperties); 。就是利用反射机制初始化对象，以及给对象的属性赋值。代码如下：
public static void configureFromProperties(Object bean, String instanceName, Properties properties) throws Exception { for(Field field : bean.getClass().getDeclaredFields()) { Class type = field.getType(); String setterMethodName = "set"+capitalizeFirstLetter(field.getName()); Method setter; try { setter = bean.getClass().getMethod(setterMethodName, new Class[] {field.getType()}); } catch(NoSuchMethodException e) { continue; // emma code coverage tool adds fields to instrumented classes - ignore them. } String getterMethodName; Method getter = null; if(field.getType().equals(Boolean.TYPE)) { getterMethodName = "is"+capitalizeFirstLetter(field.getName()); try { getter = bean.getClass().getMethod(getterMethodName, new Class[] {}); } catch (NoSuchMethodException e) {} } if(getter == null) { getterMethodName = "get"+capitalizeFirstLetter(field.getName()); getter = bean.getClass().getMethod(getterMethodName, new Class[] {}); } if(field.isAnnotationPresent(ConcatenationPrefix.class) || field.getType().getName().startsWith("java.util")) { handleGroupProperty(bean, instanceName, properties, field, setter, getter); } else { handleSimpleProperty(bean, instanceName, properties, field, setter, getter); } } }我们在回到 NarayanaXATransactionManager,分析 XARecoveryModule.getRegisteredXARecoveryModule();代码如下 ：
public static XARecoveryModule getRegisteredXARecoveryModule () { if (registeredXARecoveryModule == null) {//获取事务恢复manager RecoveryManager recMan = RecoveryManager.manager(); Vector recoveryModules = recMan.getModules(); if (recoveryModules != null) { Enumeration modules = recoveryModules.elements(); while (modules.hasMoreElements()) { RecoveryModule m = (RecoveryModule) modules.nextElement(); if (m instanceof XARecoveryModule) { registeredXARecoveryModule = (XARecoveryModule) m; break; } } } } return registeredXARecoveryModule; }重点关注获取
RecoveryManager.manager();, 最后会进入com.arjuna.ats.internal.arjuna.recovery.RecoveryManagerImple的构造方法，代码如下:
//省略了相关无用代码 // start the activator recovery loader 加载事务恢复 _recActivatorLoader = new RecActivatorLoader(); _recActivatorLoader.startRecoveryActivators(); // start the periodic recovery thread // (don't start this until just about to go on to the other stuff) //进行初始化 _periodicRecovery = new PeriodicRecovery(threaded, useListener); /* * Start the expiry scanner * * This has to happen after initiating periodic recovery, because periodic recovery registers record types used * by the expiry scanner */ ExpiredEntryMonitor.startUp();重点关注
new PeriodicRecovery(threaded, useListener);，会进行恢复模块的加载，最后会进入com.arjuna.ats.internal.arjuna.recovery.AtomicActionRecoveryModule的构造方法。
public AtomicActionRecoveryModule() { if (tsLogger.logger.isDebugEnabled()) { tsLogger.logger.debug("AtomicActionRecoveryModule created"); } if (_recoveryStore == null) { _recoveryStore = StoreManager.getRecoveryStore(); } _transactionStatusConnectionMgr = new TransactionStatusConnectionManager() ; }StoreManager.getRecoveryStore();,最后会进入com.arjuna.ats.arjuna.objectstore.StoreManager.initStore(),进入事务日志的初始化。代码如下:
private static final ObjectStoreAPI initStore(String name) { ObjectStoreEnvironmentBean storeEnvBean = BeanPopulator.getNamedInstance(ObjectStoreEnvironmentBean.class, name);//获取事务存储类型，支持的类名，默认使用 ShadowNoFileLockStore 来存储 String storeType = storeEnvBean.getObjectStoreType(); ObjectStoreAPI store; try {//进行SPI初始化加载 store = ClassloadingUtility.loadAndInstantiateClass(ObjectStoreAPI.class, storeType, name); } catch (final Throwable ex) { throw new FatalError(tsLogger.i18NLogger.get_StoreManager_invalidtype() + " " + storeType, ex); } //进行初始化 store.start(); return store; }整个方法是比较清楚的，首先获取事务日志存储的类型（默认使用 file 模式），然后进行 SPI 初始化加载，最后再初始化。
storeType 这里如果配置的是
com.arjuna.ats.internal.arjuna.objectstore.jdbc.JDBCStore,那么就会进入这个类的构造方法，来进行初始化。代码如下：
//省略无关代码 try { StringTokenizer stringTokenizer = new StringTokenizer(connectionDetails, ";"); //初始化jdbcAccess ，用来初始化 JDBCAccess jdbcAccess = (JDBCAccess) Class.forName(stringTokenizer.nextToken()).newInstance();//进行jdbc连接，datasource的初始化 jdbcAccess.initialise(stringTokenizer); _storeName = jdbcAccess.getClass().getName() + ":" + tableName; Connection connection = jdbcAccess.getConnection(); String name; int major; int minor; try { DatabaseMetaData md = connection.getMetaData(); name = md.getDriverName(); major = md.getDriverMajorVersion(); minor = md.getDriverMinorVersion(); } finally { connection.close(); } /* * Check for spaces in the name - our implementation classes are * always just the first part of such names. */ int index = name.indexOf(' '); if (index != -1) name = name.substring(0, index); name = name.replaceAll("-", "_"); name = name.toLowerCase(); final String packagePrefix = JDBCStore.class.getName().substring(0, JDBCStore.class.getName().lastIndexOf('.')) + ".drivers."; Class jdbcImpleClass = null; try { jdbcImpleClass = Class.forName(packagePrefix + name + "_" + major + "_" + minor + "_driver"); } catch (final ClassNotFoundException cnfe) { try { jdbcImpleClass = Class.forName(packagePrefix + name + "_" + major + "_driver"); } catch (final ClassNotFoundException cnfe2) { jdbcImpleClass = Class.forName(packagePrefix + name + "_driver"); } } _theImple = (com.arjuna.ats.internal.arjuna.objectstore.jdbc.JDBCImple_driver) jdbcImpleClass.newInstance(); //使用不同的数据库类型来初始化 _theImple.initialise(jdbcAccess, tableName, jdbcStoreEnvironmentBean); imples.put(key, _theImple); storeNames.put(key, _storeName); } catch (Exception e) { tsLogger.i18NLogger.fatal_objectstore_JDBCStore_2(_storeName, e); throw new ObjectStoreException(e); } }这个方法还是比较清晰的，根据我们的 jdbc 的配置，首先初始化连接信息。然后获取连接，然后根据不同的数据库类型，来进行初始化。我们来关心下
_theImple.initialise(jdbcAccess, tableName, jdbcStoreEnvironmentBean);。代码如下:
public void initialise(final JDBCAccess jdbcAccess, String tableName, ObjectStoreEnvironmentBean jdbcStoreEnvironmentBean) throws SQLException, NamingException { this.jdbcAccess = jdbcAccess; try (Connection connection = jdbcAccess.getConnection()) { try (Statement stmt = connection.createStatement()) { // table [type, object UID, format, blob] //初始化是否是否需要删除表 if (jdbcStoreEnvironmentBean.getDropTable()) { try { stmt.executeUpdate("DROP TABLE " + tableName); } catch (SQLException ex) { checkDropTableException(connection, ex); } } //是否需要创建表 if (jdbcStoreEnvironmentBean.getCreateTable()) { try { createTable(stmt, tableName); } catch (SQLException ex) { checkCreateTableError(ex); } } // This can be the case when triggering via EmptyObjectStore if (!connection.getAutoCommit()) { connection.commit(); } } } this.tableName = tableName; }框架会自动的创建事务日志表来进行存储，所以我们不需要手动创建，也不要惊讶这个表是从哪里来的。创建的表的代码如下:
protected void createTable(Statement stmt, String tableName) throws SQLException { String statement = "CREATE TABLE " + tableName + " (StateType INTEGER NOT NULL, Hidden INTEGER NOT NULL, " + "TypeName VARCHAR(255) NOT NULL, UidString VARCHAR(255) NOT NULL, ObjectState " + getObjectStateSQLType() + ", PRIMARY KEY(UidString, TypeName, StateType))"; stmt.executeUpdate(statement); }我们在回到主线
PeriodicRecovery,这个类是继承 Thread，调用 start 就会执行 run 方法，他会对控制需要进行恢复的事务线程，真的当前的事务状态进行处理，到底是阻塞，还是唤醒。初始化流程中，还有一步是进行事务恢复的，这个我们在后续的章节，单独拿出来进行讲解。
NarayanaXA 分布式事务 begin 流程
我们知道，本地的事务，都会有一个 trainsaction.begin, 对应 XA 分布式事务来说也不另外，我们再把思路切换回XAShardingTransactionManager.begin(), 会调用com.arjuna.ats.internal.jta.transaction.arjunacore.BaseTransaction.begin() 方法。代码如下:
//检查事务状态 checkTransactionState(); //获取超时配置，超时很重要 Iteger value = _timeouts.get(); int v = 0; // if not set then assume 0. What else can we do? if (value != null) { v = value.intValue(); } else v = TxControl.getDefaultTimeout(); // TODO set default timeout //初始化事务实现 TransactionImple.putTransaction(new TransactionImple(v));初始化流程主要就是检查事务状态，获取超时时间，最后也是最重要的创建事务实现。
new TransactionImple(v)。我们进入该类的构造方法，代码如下：
public TransactionImple(int timeout) {//创建事务执行action _theTransaction = new AtomicAction();//开启事务 _theTransaction.begin(timeout); _resources = new Hashtable(); _duplicateResources = new Hashtable(); _suspendCount = 0; _xaTransactionTimeoutEnabled = getXATransactionTimeoutEnabled(); _txLocalResources = Collections.synchronizedMap(new HashMap()); }这里面最重要是 2 步，第一步是初始化 AtomicAction，第二步是 AtomicAction.begin（）。我们先来看
new AtomicAction。会对相关的父类，进行初始化。AtomicAction 的继承体系图为：
我们接下来看
com.arjuna.ats.arjuna.AtomicAction.begin()。代码如下:
public int begin (int timeout) { //进行start，最关键 int status = super.start(); if (status == ActionStatus.RUNNING) { /* * Now do thread/action tracking. *///放入threadlocal里面 ThreadActionData.pushAction(this); _timeout = timeout; if (_timeout == 0) _timeout = TxControl.getDefaultTimeout(); if (_timeout > 0) //设置事务超时控制，很重要 TransactionReaper.transactionReaper().insert(this, _timeout); } return status; }我们先来分析
super.start()。最后会进入com.arjuna.ats.arjuna.coordinator.BasicAction.begin()。代码如下：
//省略很多代码//进行action的一些初始化工作 actionInitialise(parentAct);XATransactionDataSource getConnection() 流程
我们都知道想要执行 SQL 语句，必须要获取到数据库的 connection。让我们再回到 XAShardingTransactionManager.getConnection() 最后会调用到org.apache.shardingsphere.transaction.xa.jta.datasourceXATransactionDataSource.getConnection()。流程图如下：
代码 :
public Connection getConnection() throws SQLException, SystemException, RollbackException { //先检查是否已经有存在的connection，这一步很关心，也是XA的关键，因为XA事务，必须在同一个connection if (CONTAINER_DATASOURCE_NAMES.contains(dataSource.getClass().getSimpleName())) { return dataSource.getConnection(); } //获取数据库连接 Connection result = dataSource.getConnection(); //转成XAConnection，其实是同一个连接 XAConnection xaConnection = XAConnectionFactory.createXAConnection(databaseType, xaDataSource, result); //获取JTA事务定义接口 Transaction transaction = xaTransactionManager.getTransactionManager().getTransaction(); if (!enlistedTransactions.get().contains(transaction)) { //进行资源注册 transaction.enlistResource(new SingleXAResource(resourceName, xaConnection.getXAResource())); transaction.registerSynchronization(new Synchronization() { @Override public void beforeCompletion() { enlistedTransactions.get().remove(transaction); } @Override public void afterCompletion(final int status) { enlistedTransactions.get().clear(); } }); enlistedTransactions.get().add(transaction); } return result; }首先第一步很关心，尤其是对 shardingsphere 来说，因为在一个事务里面，会有多个 SQL 语句，打到相同的数据库，所以对相同的数据库，必须获取同一个 XAConnection，这样才能进行 XA 事务的提交与回滚。
我们接下来关心
transaction.enlistResource(new SingleXAResource(resourceName, xaConnection.getXAResource()));, 会进入com.arjuna.ats.internal.jta.transaction.arjunacore.TransactionImp.enlistResource(), 代码太长，截取一部分。
// Pay attention now, this bit is hairy. We need to add a new AbstractRecord (XAResourceRecord) // to the BasicAction, which will thereafter drive its completion. However, the transaction // core is not directly XA aware, so it's our job to start the XAResource. Problem is, if // adding the record fails, BasicAction will never end the resource via the XAResourceRecord, // so we must do so directly. start may fail due to dupl xid or other reason, and transactions // may rollback async, for which reasons we can't call add before start. // The xid will change on each pass of the loop, so we need to create a new record on each pass. // The add will fail in the case of multiple last resources being disallowed // see JBTM-362 and JBTM-363 AbstractRecord abstractRecord = createRecord(xaRes, params, xid); if(abstractRecord != null) { xaRes.start(xid, xaStartNormal); if(_theTransaction.add(abstractRecord) == AddOutcome.AR_ADDED) { _resources.put(xaRes, new TxInfo(xid)); return true; // dive out, no need to set associatedWork = true; } else { // we called start on the resource, but _theTransaction did not accept it. // we therefore have a mess which we must now clean up by ensuring the start is undone: abstractRecord.topLevelAbort(); } }哦多尅，看见了吗，各位，看见了
xaRes.start(xid, xaStartNormal);了吗？？？？，我们进去，假设我们使用的 Mysql 数据库：
public void start(Xid xid, int flags) throws XAException { StringBuilder commandBuf = new StringBuilder(300); commandBuf.append("XA START "); appendXid(commandBuf, xid); switch(flags) { case 0: break; case 2097152: commandBuf.append(" JOIN"); break; case 134217728: commandBuf.append(" RESUME"); break; default: throw new XAException(-5); } this.dispatchCommand(commandBuf.toString()); this.underlyingConnection.setInGlobalTx(true); }组装
XA start XidSQL 语句，进行执行。
到这里，我们总结下，在获取数据库连接的时候，我们执行了 XA 协议接口中的 XA start xid
Narayana commit 流程源码分析
我们进入com.arjuna.ats.internal.jta.transaction.arjunacore.BaseTransaction.commit() 方法，代码如下：
//获取当前事务 TransactionImple theTransaction = TransactionImple.getTransaction(); if (theTransaction == null) throw new IllegalStateException( "BaseTransaction.commit - " + jtaLogger.i18NLogger.get_transaction_arjunacore_notx()); //进行事务提交 theTransaction.commitAndDisassociate();我们重点来关注
theTransaction.commitAndDisassociate();,最后进入com.arjuna.ats.arjuna.AtomicAction.commit()代码如下:
public int commit (boolean report_heuristics) { //进行事务提交 int status = super.end(report_heuristics); /* * Now remove this thread from the action state. */ //清空数据 ThreadActionData.popAction(); TransactionReaper.transactionReaper().remove(this); return status; }最后我们会进入
com.arjuna.ats.arjuna.coordinator.BasicAction.End()方法，会首先判断是否能优化成一阶段提交，否则进行二阶段提交(二阶段提交还可以使用异步线程池方式)。代码如下:
if (doOnePhase()) { onePhaseCommit(reportHeuristics); ActionManager.manager().remove(get_uid()); } else { int prepareStatus = prepare(reportHeuristics); if (prepareStatus == TwoPhaseOutcome.PREPARE_NOTOK || prepareStatus == TwoPhaseOutcome.ONE_PHASE_ERROR) { tsLogger.i18NLogger.warn_coordinator_BasicAction_36(get_uid()); if (heuristicDecision != TwoPhaseOutcome.PREPARE_OK) { tsLogger.i18NLogger.warn_coordinator_BasicAction_37(TwoPhaseOutcome.stringForm(heuristicDecision)); } tsLogger.i18NLogger.warn_coordinator_BasicAction_38(); if (!reportHeuristics && TxControl.asyncCommit && (parentAction == null)) { TwoPhaseCommitThreadPool.submitJob(new AsyncCommit(this, false)); } else phase2Abort(reportHeuristics); /* first phase failed */ } else { if (!reportHeuristics && TxControl.asyncCommit && (parentAction == null)) { TwoPhaseCommitThreadPool.submitJob(new AsyncCommit(this, true)); } else phase2Commit(reportHeuristics); /* first phase succeeded */ } } }一阶段提交
进入方法 onePhaseCommit, 最后会调用com.arjuna.ats.internal.jta.resources.arjunacore.XAResourceRecord.topLevelOnePhaseCommit()。该方法首先会发起 XA end 语句，然后再执行 XA commit 语句。代码如下:
//省略相关代码//执行XA end语句 endAssociation(XAResource.TMSUCCESS, TxInfo.NOT_ASSOCIATED);//执行XA commit _theXAResource.commit(_tranID, true);二阶段提交
首先会进行进入
prepare(reportHeuristics);, 最后会调用com.arjuna.ats.internal.jta.resources.arjunacore.XAResourceRecord.topLevelPrepare()该方法首先会执行 XA end 语句，然后执行 XA prepare 语句。代码如下:
//省略相关代码//执行XA end语句 endAssociation(XAResource.TMSUCCESS, TxInfo.NOT_ASSOCIATED);//执行XA prepare theXAResource.prepare(_tranID)接下来进行提交，进入方法
phase2Commit, 最后会调用com.arjuna.ats.internal.jta.resources.arjunacore.XAResourceRecord.topLevelCommit()。该方法会执行 XA commit 语句。代码如下:
//省略相关代码//执行XA commit _theXAResource.commit(_tranID, fase);Narayana 回滚流程
首先我们先切换回org.apache.shardingsphere.transaction.xa.XAShardingTransactionManager.rollback() 方法，然后会进入 com.arjuna.ats.internal.jta.transaction.arjunacore.BaseTransaction.rollback() 方法，代码如下:
public void rollback() throws java.lang.IllegalStateException, java.lang.SecurityException, javax.transaction.SystemException { if (jtaLogger.logger.isTraceEnabled()) { jtaLogger.logger.trace("BaseTransaction.rollback"); } TransactionImple theTransaction = TransactionImple.getTransaction(); if (theTransaction == null) throw new IllegalStateException( "BaseTransaction.rollback - " + jtaLogger.i18NLogger.get_transaction_arjunacore_notx()); theTransaction.rollbackAndDisassociate(); }代码最后后进入
com.arjuna.ats.arjuna.coordinator.BasicAction.topLevelAbort()。代码如下:
//省略代码//先执行XA end 语句endAssociation(XAResource.TMFAIL, TxInfo.FAILED);//然后执行XA rollback_theXAResource.rollback(_tranID);接下来就是清除换成，清除事务日志。代码如下:
ActionManager.manager().remove(get_uid()); actionStatus = ActionStatus.ABORTED; if (TxStats.enabled()) { TxStats.getInstance().incrementAbortedTransactions(); if (applicationAbort) TxStats.getInstance().incrementApplicationRollbacks(); }总结 ：可以看到回滚流程会稍微毕竟简单。先执行 XA end 语句，然后执行 XA rollback 语句。
文章到此，已经写的很长很多了，我们分析了 ShardingSphere 对于 XA 方案，提供了一套 SPI 解决方案，对 Narayana 进行了整合，也分析了 Narayana 初始化流程，开始事务流程，获取连接流程，提交事务流程，回滚事务流程。下一篇文章，我们来详解 narayana 的事务恢复流程。
作者介绍：
肖宇，Apache ShardingSphere Committer，开源 hmily 分布式事务框架作者，开源 soul 网关作者，热爱开源，追求写优雅代码。目前就职于京东数科，参与 ShardingSphere 的开源建设，以及分布式数据库的研发工作。
本文转载自公众号 ShardingSphere 官微（ID：Sharding-Sphere）。
